Endgame Gear XM2w Wireless Gaming Mouse - White
The XM2w Wireless Gaming Mouse is the next generation of the acclaimed XM1r, identical in shape, but with lots of internal improvements for less weight and more consistency. State of the Art PixArt PAW3395 sensor with a dual-core STM32 wireless MCU for even better performance paired with pre-sorted Kailh switches for super crisp clicks. The updated Hybrid skate design offers two redesigned shapes for even better glide.
- PixArt PAW3395 sensor
- Pre-sorted Kailh GM 8.0 switches
- Lightweight - less than ~63g
- Dual-Core MCU for both mouse & dongle
- Lift-Off-Distance 1mm and 2mm (1mm by default)
- Hybrid skate design
- Patented analog technology - advanced algorithm for reaction time less than 1ms
Built for Competitive Play
While the XM1r was an improved version of the XM1, the XM2w is designed from scratch. The outer shape remains identical to the claw grip shape that made the XM1 famous, but on the inside, every single aspect is re-designed. Although the XM2w has a 335 mAh battery, with less than ~63g, the overall weight is about 7g lower than the XM1(r)'s. Like its predecessor, the XM2w has been developed by esports veterans for use in competitive play. It has a lightweight, yet durable shell design, with top-of-the-line components, including a PixArt PAW3395 sensor, a Dual-Core MCU for both mouse & dongle, and pre-sorted Kailh GM 8.0 switches.
Both the XM2w and its dongle use an STM32 Dual-Core MCU that incorporates a 64MHz ARM Cortex-M4 Core which handles the main tasks of the mouse and an additional 32Mhz ARM Cortex-M0 Core which exclusively manages the wireless data transmissions, ensuring high performance and advanced power-saving capabilities in all wireless modes.
Latest Pixart Sensor
The XM2w’s responsiveness significantly improves by implementing the PixArt PAW3395 featuring a higher resolution pixel array and up to 26000 CPI, Lift-Off-Distance as low as 1mm, and up to 650 IPS for best accuracy during the fastest of swipes. The PAW3395 also offers sensor-level MotionSync for consistent and synced reports. With all smoothing and angle-snapping disabled, the tracking data from the sensor is as raw as it can be. Power-saving features are either being disabled (corded connection) or optimized (wireless), squeezing every last bit of performance out of the XM2w.
Advanced switches and technology
The XM2w uses Custom Kailh GM 8.0 switches for its main buttons. These are pre-sorted, which results in a pleasant and fast click. Instead of using a Panasonic style micro switch for the middle click, the XM2w features an all-new construction using a mechanical micro switch in the form of Kailh's GM2.0. The new side button construction of the XM2w uses the same Kailh GM2.0 switches for a crisper click feeling and vastly improved durability.
Hybrid skate design
The XM2w comes with two sets of PTFE skates (large & small) and a sensor skate. Thanks to a hybrid design bottom shell, it's possible to easily install either large or small skates with the smaller skates fitted by default. The skate areas are larger than the XM1(r)'s and can work with various custom skates, including those for XM1 and XM1r. The larger area offers added flexibility when customizing the XM2w's glide and re-using already purchased skates. The sensor skate is optional but recommended on softer surfaces.
Patented Analog Technology
Like its predecessors, the XM2w can go beyond traditional signal debouncing to detect clicks thanks to its patented analog technology. It's a superior method compared to common digital approaches. Whereas digital signal processing can only detect two levels of feedback (1/0), the XM2w implements an advanced algorithm to drive faster click detection for a reaction time of less than 1ms.
Sensor: PixArt PAW3395
Resolution: 50 to 26000 CPI in steps of 50 CPI
Lift-Off Distance (LOD): 1mm and 2mm (1mm by default)
Max Speed: 650 IPS
Microcontroller: Dual-Core STM32
Polling Rate: 125, 500 and 1000 Hz (1000 Hz by default)
Ergonomics / Layout: dextral
Supported Grip Types: Made for Claw Grip. Palm Grip and Fingertip Grip possible (based on hand size)
Dimensions: approx. 122 x 38.5 x 66mm, Grip Width: 55.3 to 62mm
Primary Buttons (right/left): Pre-sorted Kailh GM 8.0 switches (80 million actuations)
Click Detection: Analog Technology (<1ms)
Number of Buttons: 6 (2x top, 2x side, 1x mouse wheel, 1x CPI on bottom)
Wheel Encoder: TTC
Mouse Wheel Scrolling: 2-way
Middle Mouse Button: pre-sorted Kailh GM 2.0 switches (20 million actuations)
Side Buttons: pre-sorted Kailh GM 2.0 switches (20 million actuations)
Materials: ABS (Chassis), PTFE (Glides), Dry Grip Coating (Surface)
Skates: Hybrid Skate Design (small skates pre-installed, large skates included)
wireless (2.4 GHz, Dongle: USB 2.0 Type A)
wired (PC: USB 2.0 Type A, Mouse: USB-C)"
Battery Capacity: 335mAh
Cable: Flex Cord 3.0 (1.80m, USB 2.0 Type A to USB-C)
