| Generelt |
| Intel H470 |
| (understøtter 10. og 11. Generation Intel Core) |
| 1 |
| LGA1200 sokkel |
| Bundkort - micro-ATX |
| Understøttet RAM |
| 2400 MHz, 2133 MHz, 2800 MHz, 2666 MHz, 2933 MHz, 3200 MHz |
| Dobbelt kanal hukommelses arkitektur, Intel Extreme Memory Profiles (XMP) 2.0, understøttede ECC-moduler fungerer i ikke-ECC-tilstand |
| 64 GB |
| Ikke bufferet |
| DDR4 |
| Ikke-ECC, ECC (drift i ikke-ECC tilstand) |
| Audio |
| Realtek ALC897 |
| High Definition Audio |
| HD Audio (8-kanaler) |
| LAN |
| Realtek RTL8111H |
| Gigabit Ethernet |
| Ekspansion / Konnektivitet |
| 1 x CPU | 2 x DIMM 288-pins | 1 x PCIe 4.0 x16 (PCIe 4.0 (11. Gen Intel CPUer), PCIe 3.0 (10. Gen Intel CPUer)) | 1 x PCIe 3.0 x1 |
| SATA-600 -stikforbindelser: 4 x 7pin Seriel ATA | SATA-600 / PCIe 3.0 -stikforbindelser: 1 x Ultra M.2 |
| 1 x HDMI | 1 x VGA | 1 x DVI-D | 4 x USB 3.2 Gen 1 | 2 x USB 2.0 | 1 x PS/2-tastatur/mus | 1 x audio linje-ind - mini-jack | 1 x audio linje-ud - mini-jack | 1 x mikrofon - mini-jack | 1 x LAN (Gigabit Ethernet) |
| 2 x USB 2.0 - intern stik | 1 x USB 3.2 Gen 1 - intern stik | 1 x audio - intern stik | 1 x SPI - intern stik | 1 x seriel - intern stik |
| Intel Rapid Storage Technology |
| 24-pin hovedstrøm-konnektor, 8-pin ATX12V-kontakt |
| Egenskaber |
| UEFI BIOS |
| AMI |
| ASRock Instant Flash, 5 Phase Power Design, ASRock XFast LAN, ASRock Internet Flash, ASRock A-Tuning, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock My Favorites in UEFI, |
| Diverse |
| 23.1 cm |
| 19.8 cm |
| 2 x Seriel ATA kabel |
| FCC, EuP Ready, ErP Ready |
| I/O- bagvæg, 1 x M.2 skrue |
