| Generelt |
| Intel B760 |
| (understøtter 12./13. og 14. Generation Intel Core / Pentium Gold / Celeron) |
| 1 |
| LGA1700 sokkel |
| Bundkort - micro-ATX |
| Understøttet RAM |
| 7200 MHz (O.C.) |
| Dobbelt kanal hukommelses arkitektur, Intel Extreme Memory Profiles (XMP) 3.0, AMD EXPO-teknologi |
| 192 GB |
| Ikke bufferet |
| DDR5 |
| Ikke-ECC |
| Audio |
| Realtek ALC897 |
| High Definition Audio |
| HD Audio (8-kanaler) |
| LAN |
| Dragon RTL8125BG |
| 2.5 Gigabit Ethernet |
| Ekspansion / Konnektivitet |
| 1 x CPU | 4 x DIMM 288-pins | 1 x PCIe 5.0 x16 | 1 x PCIe 3.0 x16 (x4-modus) | 1 x M.2 socket (2230 M.2 Key E-åbning) | 1 x M.2 socket (2242/2260/2280 M.2 Key M åbning) | 1 x M.2 socket (2280 M.2 Key M-åbning) | 1 x M.2 socket (2280 M.2 Key M-åbning) |
| SATA-600 -stikforbindelser: 4 x 7pin Seriel ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 | PCIe 4.0 -stikforbindelser: 3 x M.2 |
| 1 x PS/2-tastatur/mus | 1 x HDMI | 1 x DisplayPort | 1 x USB-C 3.2 Gen 1 | 3 x USB 3.2 Gen 1 | 2 x USB 2.0 | 1 x LAN (2.5Gigabit Ethernet) | 1 x mikrofon - mini-jack | 1 x audio linje-ind - mini-jack | 1 x audio linje-ud - mini-jack |
| 1 x USB-C 3.2 Gen 1 - intern stik | 2 x USB 3.2 Gen 1 - intern stik | 4 x USB 2.0 - intern stik | 1 x SPI - intern stik | 1 x højttaler - intern stik | 1 x audio - intern stik | 1 x Thunderbolt - intern stik |
| 24-pin hovedstrøm-konnektor, 8-pin ATX12V-kontakt |
| Egenskaber |
| UEFI BIOS |
| AMI |
| ASRock Instant Flash, ESD Protection, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Easy RAID Installer, 6 Layer PCB, Dr.MOS MOSFET, ASRock EZ Mode, ASRock Steel Slots, Water Pump Header, præmonteret I/O-skjold, Intel Turbo Boost Max Techn |
| Diverse |
| 24.4 cm |
| 24.4 cm |
| ASRock A-Tuning, ASRock Polychrome SYNC, ASRock Dragon 2.5G LAN Software |
| 2 x Seriel ATA kabel |
| FCC, EuP Ready, ErP Ready, HDCP 2.3 |
| 4 x M.2 skruer, standoff til M.2 sokkel |
