Beskrivelse
| Generelt | |
|---|---|
| Produkttype | Bundkort - ATX |
| Chipsættype | AMD B550 |
| Processor-socket | Socket AM4 |
| Max antal processorer | 1 |
| Kompatible processorer | Ryzen (understøtter 3. Generation Ryzen and New Generation Ryzen med Radeon Graphics) |
| Understøttet RAM | |
| Maks. størrelse | 128 GB |
| Teknologi | DDR4 |
| Bus Clock | 2400 MHz, 2133 MHz, 2667 MHz, 2933 MHz, 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3800 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4200 MHz (O.C.), 4333 MHz (O.C.), 4600 MHz (O.C.), 4533 MHz (O.C.), 3200 MHz, 4666 MHz (O.C.), 4733 MHz (O.C.), 4466 MHz (O.C.) |
| Understøttet RAM-integritetskon | Ikke-ECC, ECC (drift i ikke-ECC tilstand) |
| Registreret eller buffer | Ikke bufferet |
| Egenskaber | Dobbelt kanal hukommelses arkitektur, AMD Memory Profile (AMP), understøttede ECC-moduler fungerer i ikke-ECC-tilstand |
| Grafik | |
| Maks. allokeret RAM-størrelse | 2 GB |
| Audio | |
| Type | HD Audio (8-kanaler) |
| Audio codec | Realtek ALC1200 |
| Overensstemmelsesstandarder | High Definition Audio, Premium Blu-ray audiosupport |
| LAN | |
| Netværk controller | Realtek RTL8111H |
| Netværks interfaces | Gigabit Ethernet |
| Ekspansion / Konnektivitet | |
| Ekspansionsåbninger | 1 x CPU 4 x DIMM 288-pins 1 x PCIe 4.0 x16 (PCIe 4.0 x16 tilstand (Ryzen-serie CPUer Matisse); PCIe 3.0 x16 tilstand (Ryzen-serie APUer)) 1 x PCIe 3.0 x16 (x4-modus) 2 x PCIe 3.0 x1 1 x M.2 socket (2230 M.2 Key E-åbning) |
| Grænseflade (lagring) | SATA-600 -stikforbindelser: 6 x 7-pin Seriel ATA - RAID 0 / RAID 1 / RAID 10 SATA-600 / PCIe 3.0 -stikforbindelser: 1 x M.2 PCIe 4.0 -stikforbindelser: 1 x M.2 |
| Interface | 1 x LAN (Gigabit Ethernet) 1 x HDMI 6 x USB 3.2 Gen 1 1 x mikrofon - mini-jack 1 x audio linje-ind - mini-jack 1 x audio linje-ud - mini-jack 1 x PS/2-tastatur/mus |
| Interne interfaces | 4 x USB 2.0 - intern stik 2 x USB 3.2 Gen 1 - intern stik 1 x audio - intern stik 1 x seriel - intern stik |
| Strømkontakter | 4-pin ATX12V konnektor, 24-pin hovedstrøm-konnektor, 8-pin ATX12V-kontakt |
| Egenskaber | |
| BIOS-type (Basic Input/Output System) | AMI |
| BIOS-egenskaber | JumperFree, SMBIOS 2.3 understøttet, UEFI BIOS, ACPI 5,1 support |
| Hardwareovervågning | CPU kernetemperatur, chassis temperatur, takometer til CPU-blæser, takometer til chassis-blæser, systemspænding, CPU kerne-spænding |
| Sov/ Vågn | Aktivering af LAN (wake on LAN = WOL) |
| Hardware egenskaber | 8 Phase Power Design, ASRock Instant Flash, HDCP kompatibel, 15µ Gold Contact, AMD CrossFireX-teknologisupport, AMD Quad CrossFireX-teknologisupport, Digi Power Design, ESD Protection, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), ASRock Key Master, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, Sapphire Black PCB, XXL Aluminum Alloy Heatsink, Nahimic Audio Enhacer, ASRock Live Update, Premium 50A Power Choke, PCB Isolate Shielding, 2oz Copper PCB, ASRock POST Status Checker (PSC), ASRock Steel Slot Gen4, ASRock Hyper M.2 |
| Diverse | |
| Udstyr inkluderet | I/O- bagvæg, 3 x M.2 skruer |
| Medfølgende ledninger | 2 x Seriel ATA kabel |
| Med software | Drivers & Utilities, Antivirus (prøveversion), Google Chrome Browser, Google ChromeToolbar, ASRock XFast LAN, ASRock Phantom Gaming Tuning, ASRock Polychrome SYNC |
| Overensstemmelsesstandarder | Plug and Play, FCC, EuP Ready, ErP Ready, HDCP 2.3 |
| Bredde | 30.5 cm |
| Dybde | 24.4 cm |
| Producentgaranti | |
| Service & Support | Begrænset garanti - 3 år |
